Standard Brick Size & Dimensions (Inches & MM)
Table of Contents
Standard Brick Size & Dimensions (Inches & Mm)
[su_table responsive=”yes” class=”rk”]
|
Size of the Brick |
Dimensions in ( Inches ) ( Depth X Height X Length) |
Dimensions in ( mm ) |
Modular Brick |
3 – 5/8″ x 2 – 1/4″ x 7 – 5/8″ | 92 mm x 57 mm x 194 mm |
Standard Brick |
3 – 5/8″ x 2 – 1/4″ x 8″ | 92 mm x 57 mm x 203 mm |
Jumbo Modular Brick |
3 – 5/8″ x 2 – 3/4″ x 7 – 5/8″ | 92 mm x 70 mm x 194 mm |
Jumbo Standard Brick |
3 – 5/8″ x 2 – 3/4″ x 8″ | 92 mm x 70 mm x 203 mm |
Jumbo Standard ( PLT 3) |
3 – 5/8″ x 2 – 5/8″ x 8″ | 92 mm x 67 mm x 203 mm |
Slim Jumbo Modular |
3 – 1/8″ x 2 – 3/4″ x 7 – 5/8″ | 76 mm x 70 mm x 194 mm |
Queen Brick |
3 – 1/8″ x 2 – 3/4″ x 9 – 5/8″ | 79 mm x 70 mm x 244 mm |
Roman Brick |
3 – 1/8″ x 2 – 3/4″ x 9 – 5/8″ | 92 mm x 41 mm x 295 mm |
Norman Brick |
3 – 1/8″ x 2 – 3/4″ x 9 – 5/8″ | 92 mm x 57 mm x 295 mm |
Jumbo Norman Brick |
3 – 5/8″ x 2 – 3/4″ x 11 – 5/8″ | 92 mm x 70 mm x 295 mm |
Slim Jumbo Norman |
3 – 1/8″ x 2 – 3/4″ x 11 – 5/8″ | 79 mm x 70 mm x 295 mm |
Modular Economo |
3 – 5/8″ x 3 – 5/8″ x 7 – 5/8″ | 92 mm x 92 mm x 194 mm |
Utility Brick |
3 – 5/8″ x 3 – 5/8″ x 11 – 5/8″ | 92 mm x 92 mm x 295 mm |
Monarch Brick |
3 – 5/8″ x 3 – 5/8″ x 15 – 5/8″ | 92 mm x 92 mm x 397 mm |
Quad Brick |
3 – 5/8″ x 7 – 5/8″ x 7 – 5/8″ | 92 mm x 194 mm x 194 mm |
Ambassador Brick |
3 – 5/8″ x 2 – 1/4″ x 15 – 5/8″ | 92 mm x 57 mmx 397 mm |
Double Utility Brick |
3 – 5/8″ x 7 – 5/8″ x 11 – 5/8″ | 92 mm x 194 mm x 295 mm |
Double Monarch |
3 – 5/8″ x 7 – 5/8″ x 15 – 5/8″ | 92 mm x194 mm x 397 mm |
6″ X 4″ X 16″ Thru – Wall |
5 – 5/8″ x 3 – 5/8″ x 15 – 5/8″ | 143 mm x 92 mm x 397 mm |
8″ X 4″ X 16″ Thru – Wall |
7 – 5/8″ x 3 – 5/8″ x 15 – 5/8″ | 194 mm x 92 mm x 397 mm |
8″ X 8″ X 16″ Thru – Wall |
7 – 5/8″ x 7 – 5/8″ x 15 – 5/8″ | 194 mm x 194 mm x 407 mm |
[/su_table]
Standard Brick Sizes in England
The majority of bricks in the United kingdom are manufactured to a regular brick scale of 215 mm long, 102.5 mm wide, about 65 mm high ( 215 mm x 102.5 mm x 65 mm) as well as placed with a minimal 10 mm mortar joint.
There seems to be, nevertheless, an increasing movement toward non-standard brick sizes, including such Wienerberger’s Roman and Megaline bricks.
Longer, narrower sizes are popular right now, with brick heights of less than 50 mm and brick lengths of more than 500 mm not unusual. Architects and engineers are using these brick sizes to allow these modern designs stand out in a crowd.
1. Roman Brick Range
The Roman range’s brick dimensions are 400 mm x 100 mm x 40 mm. These exclusive bricks are manufactured on a customized line, giving them a distinct personality.
The combination of modern brick proportions, a wide range of colours, and distinct textures makes these bricks ideal for designers looking to add a sense of exclusivity and prestige to a project.
2. Megaline Brick Range
The Megaline collection is ideal for designing a sleek, contemporary look. The Megaline brick dimensions are 288 mm x 88 mm x 48 mm.
Standard Brick Sizes in the United States
The scale of good quality bricks should be consistent. According to ASTM, the standard dimension of a brick in the United States is 203 mm x 92 mm x 57 mm ( length x width x thickness ). The most popular modular brick scale is 194 mm x 92 mm x 57 mm.
This is the finest, optimal, fine, standardised, regular, widely used, and nominal size of brick used in house building in the United States.
Standard Brick Sizes in Australia
The standard brick scale in Australia, according to Australian standard AS 4455, is 230 x mm 110 mm x 76 mm ( length x width x thickness ). This is the finest, optimal, fine, uniform, widely used, and nominal size of brick used in house building in Australia.
Some brick dimensions, such as 290 mm x 90 mm x 90 mm and 290 mm x 90 mm x 50 mm, are also used.
Standard Size of Brick in India
In India, there are two types of bricks: regular bricks and nominal bricks. According to BIS, the normal brick scale is 190 mm x 90 mm x 90 mm. The length of the brick becomes 200 mm x 100 mm x 100 mm with mortar thickness, which is also considered as the nominal scale of the modular brick.
Traditional Size of Brick in Inches
Standard brick sizes in inches range from 8′′ to 10′′ in length, 4′′ to 5′′ in width, and 2′′ to 3 ′′ in thickness. The widely used nominal scale conventional / traditional brick is roughly 9” x 4 12 “ x 3 ”.
Conventional Size of Brick in mm
Length ranges from 200 to 250 mm, the width from 100 to 130 mm, and the thickness ranges from 50 to 75 mm. The standard nominal scale for traditional/conventional brick is 230 mm x 114 mm x 76 mm.
Types of Standard Size in India
Standard size of brick used in india are two types.
- Modular Brick
- Non Modular Brick
Standard Size of Brick in mm Are Following
Modular brick dimensions ( l x b x h ) i.e., 190 mm x 90 mm x 90 mm and 190 mm x 90 mm x 40 mm. Non modular brick sizes ( l x b x h ) i.e., 230 mm x 110 mm x 70 mm and 230 mm x 110 mm x 30 mm can also be used.
Bricks of 90 mm and 70 mm height are provided with a frog dimension 10 mm to 20 mm deep on one of their flat sides; however, bricks of 40 mm and 30 mm height, as well as those rendered by extrusion operation, are not provided with frog.
Standard Size of Brick in Inches Are Following
Modular brick dimensions (l × b × h) – 7.5 ″ × 3.5 ″ × 3.5 ″ and 7.5 ″ × 3.5 ″ × 1.5 ″ Non modular brick sizes (l × b × h) – 9 ″ × 4.3 ″ × 2.75 ″ & 9 ″ × 4.3 ″ × 1.18 ″ can also be used.
Bricks of 5 ″ & 2.75 ″ height are provided with a frog dimension 0.4 ″ to 0.8 ″ deep on one of their flat sides; however; bricks of 1.5 ″ & 1.18 ″ height, as well as those rendered by extrusion operation, are not provided with frog.
Standard Brick Sizes in Nepal
The regular brick must be 240 mm long, 115 mm wide, and 57 mm thick, with a tolerance of + / -10 mm on weight, + / -5 mm on width, and + / -3 mm on thickness, according to Nepal National Building Code ( NBC 109 : 1994 ). In reality, however, the size of the bricks produced varies greatly across the world. Bricks manufactured in the Terai area are usually larger in size than those manufactured in the Kathmandu valley.
The below are the different sizes of bricks available on the market :
- Length 230 mm – 250 mm.
- Breadth 110 mm – 120 mm.
- Thickness 50 mm – 75mm.
The Nepal Building Code ( NBC ) specifies a crushing strength of 35 kg / cm2 for brick. In fact, however, the crushing power is typically greater than 7. According to the Nepal Building Code, the water absorbance of bricks should be 15 % for machine-made bricks, but it can be up to 25 % for hand-molded bricks.
[su_box title=”FAQ” style=”default” box_color=”#333333″ title_color=”#FFFFFF” radius=”3″ class=”” id=””]
Brick Size
The standard co-ordinating size for brickwork is 225 mm x 112.5 mm x 75 mm (length x depth x height). This includes 10 mm mortar joints, and so the standard size for a brick itself is 215 mm x 102.5 mm x 65 mm (length x depth x height).
Brick Paver Dimensions
The most commonly used paver brick size is 4″ x 8″ (10cm x 20cm in the metric system). However, other sizes are not rare at all. If you happen to need to calculate a brick’s volume, the thickness is usually 2″ (5 cm). The only exceptions are the 14″ x 14″ and the 12″ x 18″ bricks.
King Size Brick
King size brick are 9 5/8″ l x 2 5/8″ h x 2 3/4″ thru the wall, for a nominal face dimension of 10″ x 3″ with a standard 3/8″ mortar joint. They conform to astm c652 and are made at most acme brick plants. Use of acme king size brick results in lower labor cost, lower mortar cost, and faster construction time.
Retaining Wall Block Sizes
For heavy-duty walls up to 30 ft. Tall, go with full-size blocks. They’re 16 to 18 in. Long x 6 to 8 in.
Glass Block Dimensions
[su_table responsive=”yes” class=”rk”]
| Glass Block Types and Patterns U.S. Sizing | Nominal Glass Block Sizes | Exact Glass Block Sizes |
| 6″ X 6″ X 4″ | 5 3/4″ X 5 3/4″ X 3 7/8″ | |
| Cross Ribbed | 8″ X 8″ X 4″ | 7 3/4″ X 7 3/4″ X 3 7/8″ |
| Light Diffusing | 8″ X 8″ X 4″ | 7 3/4″ X 7 3/4″ X 3 7/8″ |
| Nubio | 8″ X 8″ X 4″ | 7 3/4″ X 7 3/4″ X 3 7/8 |
[/su_table]
Retaining Wall Blocks Dimensions
To keep the bottom row of blocks from pushing outward, bury the lowest section of a retaining wall. The general rule of thumb is to bury about one-eighth of the height of the wall. For example, if your wall will be three feet (36 inches) tall, the first course of blocks should start five inches below soil level.
Paving Brick Size
Clay paving bricks usually come in face sizes of 4 by 8 inches, but other sizes are available. Face sizes are also available in both 3 5/8 by 7 5/8 inches and 3 by 7 inches. Thickness can vary between 1 1/4 inches and 2 1/4 inches, the latter being the most popular.
8 Inch Glass Block
[su_table responsive=”yes” class=”rk”]
Material |
Average Cost (Per Block) |
| Clear Glass | $10 – $50 |
| Colored Glass | $25 – $75 |
| Acrylic | $30 – $95 |
[/su_table]
Standard Glass Block Size
Glass blocks made for windows are commonly 8” x 8” square. The standard window size is 32” wide by 16” tall such as a basement glass block window. Some manufacturers create glass blocks with sizes including 6” x 6” and 4” x 4”.
Custom Size Glass Block Windows
Glass blocks made for windows are commonly 8” x 8” square. The standard window size is 32” wide by 16” tall such as a basement glass block window. Some manufacturers create glass blocks with sizes including 6” x 6” and 4” x 4”.
[/su_box]
