What Is Bridge Abutment | 5 Types of Abutments
Bridge Abutment Means
As a component of a bridge, the abutment provides the vertical support to the bridge superstructure at the bridge ends, connects the bridge with the approach roadway, and retains the roadway base materials from the bridge spans.
Although there are numerous types of abutments and the abutments for the important bridges may be extremely complicated, the analysis principles and design methods are very similar.
In this article, the topics related to the design of conventional highway bridge abutments are discussed and a design example is illustrated.
Unlike the bridge abutment, the earth-retaining structures are mainly designed for sustaining lateral earth pressures.
What Is Bridge Abutment?
A bridge abutment is a substructure that supports one terminus of the superstructure of a bridge and, at the same time, laterally supports the embankment which serves as an approach to the bridge.
For a river bridge, the abutment also protects the embankment from scour of the stream.
Bridge abutments can be made of masonry plain concrete or reinforced concrete.
Also Read: What Is Bridge Pier | Type of Bridge Pier
